Trusses+

價格:免費

更新日期:2017-05-03

檔案大小:11.7 MB

目前版本:1.2

版本需求:需要 iOS 8.0 或以上版本。與 iPad 相容。

支援語言:英語

Trusses+(圖1)-速報App

Trusses+ is dedicated to the pre-design of Large Span Trusses in conformity with the European rules for steel structures (EN1993-1-1:2005)

The software can be used as an automatic pre-design tool.

Verification: based on sections imposed by the user, Trusses+ checks the design criteria of each member of a truss (upper and lower chords, bracings)

Optimization: from basic data supplied by the user (main geometry, lateral restraints and loadings), the software estimates the dimensions of the cross-section of elements of the structure

The field of application of Trusses+ is:

2 dimensional truss model, simply supported, with user defined positions of lateral restraints

Truss configurations: N-, V-, A-truss, Warren, Pratt, Warren plus, Pratt lattice & Warren lattice

Geometrical limits:

Length = min: 5m, max: 100m

Trusses+(圖2)-速報App

Height = min: 0.2m, max: 10m

Height/Length ratio = min 1/30, max: 1/10

Program sales of ArcelorMittal for I, H, double L, and U-sections

Steel grades and standards : EN 10025-2 & 4, EN 1993-1-1, HISTAR S355&S460

Multiple loading cases with definitions of:

Distributed loads: Permanent, Imposed, Wind and Snow loads

Concentrated loads: Permanent and Imposed loads

The calculations performed according to Eurocodes are:

Trusses+(圖3)-速報App

Automatic load combination of the elementary load cases for Ultimate Limit States (ULS) and Servicability Limit States (SLS)

Classification of sections

Verification of cross-section resistance

Verfication of the member stability: flexural buckling in-plane and out-of plane

Verification of deflection limits and estimation of natural frequencies (SLS)

The results are provided as:

vizualisation on the software interface

3 levels of details of Preliminary Design Notes, with:

Data of the truss and calculation parameters

Trusses+(圖4)-速報App

Analysis results (reaction at supports, node displacements, internal forces)

Verification results (ULS and SLS)

Trusses+(圖5)-速報App

支援平台:iPad
